Sealite – LED Port Entry Light (PEL) SL-PEL Series -5°

Sealite – LED Port Entry Light (PEL) SL-PEL Series -5°

The Sealite SL-PEL-10 is a 10 degree LED Sectored Port Entry Light which provides an overall 10 degree beam width and over 120,000cd at 30 watts.

Features

  • Stationary intensity of up to 120,000cd (white) with a night-time visible range of up to 20NM
  • 3.5NM visible day-time range
  • High precision light sectoring – measured changeover between colour sectors of typically one minute of arc
  • Low power consumption – uses 30 watts to achieve intensities that previously required 250Watts, making solar power feasible
  • LEDs can be configured for automatic night dimming, eliminating the need for moving filters
  • LEDs can be individually flashed to reduce the need to employ moving oscillating boundaries
  • Ultra-compact design, removing the need for split-assemblies & realignment on difficult access sites
  • Operates on 12-24VDC battery supply – no need for large cables
  • Extremely robust & of high quality construction
  • Convenient PC Programming via USB
  • Multiple configurations & maintenance-free

Specifications

Specifications
Light Source LED
Visible Range (NM) @ 0.74: up to 20 (Night)
Nominal Voltage (V) 12-24 (VDC)
Beam width overall (Degrees) 10
Warranty 3 Year
Optional AIS Type 1 or 3

Downloads

Download Data Sheets
