Mooring Buoys 2400

North West Marine offers an extensive portfolio of navigation buoys designed in compliance with strict quality standards and validated by a strong history of reliability. Tritonbuoys has developed a diverse selection of mooring buoys that adhere to rigorous quality standards and boast a proven track record of reliability. Each buoy is manufactured from premium UV-stabilized virgin polyethylene and filled with closed-cell polyurethane to prevent water ingress in the event of damage.

Tritonbuoys mooring buoys feature a robust molded center pipe, specifically designed to facilitate the easy installation of mooring tubes and chains. This design enhances the functionality and versatility of the buoys, making them ideal for various mooring applications.

Features

  • Excellent buoyancy and stability.
  • Sturdy construction.
  • Range of colours.
  • Easy assembly and installation.

Specifications

TM MB 2400
Diameter2400 mm
Available ColourGreen, Red, Yellow, White as per IALA recommendations; Customisation Available.
Total Float Volume4390 L
Nominal Freeboard900 mm
Nominal Draft700 mm
Total Reserve Buoyancy3770 kg
Operational Buoyancy1830 kg
Maximum Mooring Load1830 kg
Draft, Maximum1100 mm
Freeboard, Minimum500 mm
Physical Characteristics
MaterialRotationally-Moulded UV Stabilized Virgin Polyethylene
Wall Thickness14mm Buoy Section; 7mm Top Section
Ballast (Internal Concrete)600 kg (Customisable)
FillingClosed cell Polyurethane (Density > 45kg/m³)
Total Height1600 mm
Width2400 mm
Mass1070 kg (including ballast & mooring rod)
Certifications
IALASurface colours compliant to IALA E-108
Quality AssuranceISO9001:2015
Warranty3 Years**
IP/TrademarkTRITONBUOYS® is a registered trademark
Options Available
Custom Mooring Rod, Custom Signage, Internal Radar Reflector, Navigation/Signal Lights, Pickup Buoy
* Specifications subject to change or variation without notice
** Warranty subject to terms & conditions
